Features:

This data sheet specifies the operation of the unifiedLPDDR4 and LPDDR4X product, and first describesspecific requirements for LPDDR4X 0.6V VDDQ operation. When using the product as an LPDDR4 device,refer to LPDDR4 setting section LPDDR4 1.10V VDDQat the end of this data sheet.

• Ultra-low-voltage core and I/O power supplies

– VDD1 = 1.70–1.95V; 1.80V nominal

– VDD2 = 1.06–1.17V; 1.10V nominal

– VDDQ = 1.06–1.17V; 1.10V nominalor Low VDDQ = 0.57–0.65V; 0.60V nominal

• Frequency range

– 2133–10 MHz (data rate range: 4266–20 Mb/s/pin)

• 16n prefetch DDR architecture

• 8 internal banks per channel for concurrent operation

• Single-data-rate CMD/ADR entry

• Bidirectional/differential data strobe per byte lane

• Programmable READ and WRITE latencies (RL/WL)

• Programmable and on-the-fly burst lengths (BL =16, 32)

• Directed per-bank refresh for concurrent bank operation and ease of command scheduling

• Up to 8.5 GB/s per die

• On-chip temperature sensor to control self refreshrate

• Partial-array self refresh (PASR)

• Selectable output drive strength (DS)

• Clock-stop capability

• RoHS-compliant, “green” packaging

• Programmable VSS (ODT) termination

• AEC-Q100
