Description：

The ESD7462 is designed to protect voltage sensitive componentsthat require ultra−low capacitance from ESD and transient voltageevents. It has industry leading capacitance linearity over voltagemaking it ideal for RF applications. This capacitance linearitycombined with the extremely small package and low insertion lossmakes this part well suited for use in antenna line applications forwireless handsets and terminals.

Features：

 Industry Leading Capacitance Linearity Over Voltage

• Ultra−Low Capacitance: 0.3 pF Typ

• Insertion Loss: 0.05 dB at 1 GHz; 0.10 dB at 3 GHz

• Low Leakage: < 1 nA Typ

• Protection for the following IEC Standards:

♦ IEC61000−4−2 (ESD): Level 4

♦ IEC61000−4−4 (EFT): 40 A −5/50 ns

♦ IEC61000−4−5 (Lightning): 1 A (8/20 s)

• Protection for ISO 10605 (ESD)

• SZESD7462MXWT5G

− Wettable Flank Package for OptimalAutomated Optical Inspection (AOI)

• SZ Prefix for Automotive and Other Applications Requiring UniqueSite and Control Change Requirements; AEC

−Q101 Qualified andPPAP Capable

• These Devices are Pb−Free, Halogen Free/BFR Free and are RoHSCompliant

Typical Application：

• RF Signal ESD Protection

• RF Switching, PA, and Antenna ESD Protection

• Near Field Communications

• USB 2.0, USB 3.0
